Specifically, it works with complex surface skins with multiple holes, open loops, and the like as is typical in the automotive industry and with Body In White in particular. But the VISI version differs in that it allows you to work with more complex parts.
#Visi series v15 download skin
Draping surfaces is available in other systems, where a surface is theoretically dropped onto a collection of points or surfaces to create a single skin that covers the entire form. An interesting new feature is Drape Surface. VISI is a hybrid modeling system - as any system for the mold and die industry should be - so you can create and modify both complex surfaces and solids equally. Finally, you can display a model at 1:1 scale (you input your screen size and it adjusts) and you can display the models in perspective mode. There are a lot of updates to make your displays more efficient, such as quality control, more powerful dynamic sections with controls for capping and hatching sectioned faces. You can also customize the colors of specific hole types to make design data less ambiguous. On the same subject, threaded holes are now displayed using a threaded bitmap representation, which is going to be really useful for those designing complex molds: It’ll be immediately clear whether a hole is threaded or not. Plus, reflection mapping is now available, allowing you to use any bitmap image or industry standard zebra striping for surface evaluation. Geometry display has also received much attention. For example, typing BLE will give you all of the blending commands. This allows you to quickly type in a search string that pops up a list of commands that match that string. It supports all modern requirements in terms of graphic display and functional dual-monitor support (something big-name CAD vendors haven’t yet got right).Īt the base of the UI, you’ll find a small text entry box. This updating has been extended to areas such as geometry definition, modification, and manufacturing-process support.Īs a result, today’s VISI interface is clean and fresh, which helps with initial training. So, with this in mind, Vero began a process of looking at the system a few releases back, improving it and bringing it up to date with a complete reworking of the interface. Of course, when you have a system with such breadth of functionality and knowledge built up over many years, you also find that the user experience starts to suffer.
#Visi series v15 download windows
The system covers everything from 2D and 3D CAD (it was the first system to implement Parasolid on the Windows platform) to mold, die, and electrode design and analysis, as well as a whole host of machining covering everything from 2.5- to 5-axis milling.
The company has been building its depth of knowledge and impressive level of detail in process and task support for the mold, die, and machining industry for the past three decades. One of the leaders in the latter category is UK-based Vero Software. There are general-purpose CAD tools providing basic CAM support and then there are those heavily engaged in the production environment developing tools to solve real manufacturing issues. There is a clear split in the vendors operating in the CAD/CAM industry.
#Visi series v15 download code
NC Optimiser is a postprocessing tool that executes after NC code has been generated, performing a real-time analysis of forces on the machine tool (feed rate) compares it with the stock left on geometry and optimizes the feed rate accordingly.
